product name

GE PVM9215SK3SS Microwave Or Advantium

Model: PVM9215SK3SS

Save
 Part Not Listed?Part Not Listed?
product name

CONTROL PARTS

...
...
98
STAINLESS STEEL CONTROL PANEL WHITE LED GEH-WB56X30177
...
99
KNOB, DIAL GEH-WB03X20765
...
105
BRACKET C/PANEL ASM GEH-WB34X26809
...
110
PCB MAIN ASM GEH-WB27X26810

DOOR PARTS

...
...
87
END CAP, DOOR GEH-WB06X10947
...
88
STAINLESS STEEL DOOR WITH FLAT GE LOGO GEH-WB56X30289
...
89
HANDLE ASM, SS GEH-WB15X26821
...
9999
TEMPLATE REAR GEH-49-40336
...
9999
PM MINI MANUAL GEH-31-30789
...
9999
TOP TEMPLATE GEH-31-41061
...
9999
PM INSTALLATION INSTRUCT GEH-49-40765
...
9999
PM QUICK USE AND CARE GEH-49-40770
...
9999
PM USERS MANUAL GEH-49-40768

OVEN CAVITY PARTS

...
...
3
BASE, BOTTOM GEH-WB63X10072
...
4
BRACKET-BOTTOM LAMP GEH-WB34X26805
...
5
CABLE CLAMP GEH-WB01X26804
...
6
COVER-GLASS GEH-WB36X10216
...
7
GLASS COOKTOP LAMP GEH-WB36X10071
...
8
SOCKET HALOGEN LAMP GEH-WB02X26814
...
10
SPRING-BLADE GEH-WB09X10042
...
15
PLATE, BASE GEH-WB63X10071
...
16
THERMOSTAT GEH-WB20X10059
...
17
TRANS H.V GEH-WB27X10910
...
19
BLADE, FAN GEH-WB02X20626
...
22
HOLDER-WIRE GEH-WB06X10819
...
23
MOTOR, FAN GEH-WB26X10262
...
24
THERMO SWTCH GEH-WB27X709
...
25
MAGNETRON ASM GEH-WB27X11079
...
26
WIRE-SADDLE GEH-WB01X10408
...
27
PCB SUPPORT GEH-WB4X175
...
28
POWER CORD ASM GEH-WB18X10491
...
29
THERMOSTAT ASM W/ BRKT GEH-WB24X26785
...
31
MAGNETRON TCO GEH-WB24X29270
...
32
CAPACITOR- MOTOR GEH-WB27X10170
...
33
TURNTABLE, MOTOR GEH-WB26X10233
...
34
THERMOSTAT GEH-WB20X10060
...
36
LATCH, BODY GEH-WB14X10051
...
37
LEVER-S/W GEH-WB06X10128
...
38
SWITCH-MICRO GEH-WB24X10075
...
39
SWITCH GEH-WB24X10038
...
40
NOISE FILTER, ASM GEH-WB02X20624
...
41
MAIN WIRE HARNESS ASM GEH-WB18X26808
...
42
BRACKET-HVC GEH-WB06X10713
...
43
CAPACITOR 2100V/0.91 MIC GEH-WB27X10011
...
44
DIODE ASSY GEH-WB27X1160
...
45
MOTOR VENTILATION GEH-WB26X26897
...
46
DUCT, REAR GEH-WB39X10037
...
47
GUIDE, ROLLER ASM GEH-WB02X10839
...
48
TRAY, COOKING GEH-WB39X10038
...
50
NUT TOP MOUNTING GEH-WB01X10071
...
52
BLADE, STIRRER GEH-WB06X10888
...
53
HOLDER-STIRRER GEH-WB06X10813
...
54
ASM HOOD DAMPER GEH-WB06X10920
...
55
COVER, STIRRER GEH-WB34X20622
...
56
BUTTON, LOCKING GEH-WB03X10336
...
57
COUPLER GEH-WB06X10815
...
58
COVER MGT GEH-WB02X28880
...
60
FILTER, AIR GEH-WB02X11534
...
61
GUIDE, VENT AIR GEH-WB39X10036
...
63
HARNESS WIRE GEH-WB18X10494
...
67
HOLDER-SENSR GEH-WB6X549
...
68
GAS SENSOR GEH-WB24X799
...
72
HOLDER, HALOGEN LAMP GEH-WB06X10882
...
73
SOCKET, LAMP GEH-WB08X10067
...
74
COVER, LAMP GEH-WB06X10884
...
75
LAMP, HALOGEN(50W) GEH-WB25X10026
...
76
HARDWARE ASM GEH-WB06X10889
...
82
PLATE MOUNTING ASM GEH-WB56X10446
...
83
CASE OUTER SS GEH-WB56X26904
...
85
CHARCOAL FILTER GEH-WB02X11544
...
86
GRILLE VENT SS GEH-WB07X26903
...
113
FUSE GEH-WB27X10474
...
...
...
