product name

CleanMax CMBP-6.2 Upright Vacuum

Model: CMBP-6.2

Save
 Part Not Listed?Part Not Listed?
product name

CleanMax CMBP-6.2

...
...
1
Top Cover B352-0500
...
2
Hose Inlet B352-0600
...
3
Paper Bag (10 Pack) C352-2500
...
4
Shake Out Cloth Bag C352-1400
...
5
Bag Compartment Seal B352-6100
...
6
Phillips Pan Head #8 X .625 Hi Lo A732-8314
...
7
Back Plate B352-0443
...
8
Socket 34864
...
9
Power Cord X9714
...
10
Plug Cover With Screws X1299
...
11
Button Kit X1283
...
12
Phillips Pan Head #8 16 X 2.5 A430-0205
...
13
Secondary Filter Cap B352-1000
...
14
Hepa Secondary Filter B352-2401
...
15
Secondary Filter Plate B352-0800
...
16
Body Seal B352-1200
...
17
Motor Cap B352-0700
...
18
Front Cover BA00033671
...
19
Top Motor Mount B352-1800
...
20
Motor Shroud Top B352-5400
...
21
Motor Assembly D123-5310
...
22
Bottom Shroud B352-5300
...
23
Phillips Pan Head #6-32 X 3/4 Hi Lo X8243
...
24
Thermal Protector Switch D123-1000
...
25
Bottom Motor Mount B352-1900
...
26
Motor Compartment X1285
...
27
Bumper (Nla) B352-0200
...
28
Post Filter B352-2400
...
29
Post Filter Frame B352-1100
...
30
Cord Retainer Hook B352-6900
...
31
Screw #10 X .750 (Nla) A352-8100
...
32
Harness Frame B352-1300
...
33
Harness 33860
...
34
Inlet Seal B352-4800

CleanMax CMBP-6.2

...
...
1
Hose Assembly A352-6900
...
2
2 Pc Wand Set CT171-CS
...
3
Carpet Tool B352-PF10
...
4
Dusting Brush Tool CT184
...
5
Upholstery Tool CT188
...
6
Crevice Tool CT176
...
7
Floor Brush Assembly C352-PF20
...
8
Easy Glide Carpet Tool CT190
...
...
...
