Windsor Saber Blade 12
Saber Blade 12 Most Popular:
Add to My Models

saber blade 12

1. Switch Two-Pole 66304340
2. Screw 5X20 -A2-70 (In6Rd) 73032120
3. Screw 5X40 -A2-70 (In6Rd) 73031180
4. Handhold Complete Replacement 40331700
5. Handle Alu 50332280
6. Spring Handle 50331950
7. Catch For Cable Grey 50334940
8. Plug Handle 50331960
9. Screw 5X16 -10.9-P2R (K-In6Rd) 73031070
10. Covering Cap Cable 50331750
11. Covering Cap Housing Replacement 40331620
12. Housing 50331720
13. Power Cable 10M *Usa 66496000
14. Sleeve Suction Tube Grey 50334960
15. Suction Pipe Tank 50331790
16. Sealing Lip Swt-Sl-Sb 53636880
17. Suction Pipe Turbine 50331780
18. Switch 66303850
19. Sealing Lip Swt-Sl-T 53636870
20. Distribution Circuit Board Br 30/4 C 66829740
21. Screw 5X16 -A2-70 (In6Rd) 73031040
22. Funnel Valve 50331900
23. O-Ring Seal 27,0 X 3,0 63626040
24. Motor Housing 50331730
25. Flap Ventilation 50331740
27. Sealing Lip Vac Motor Sl 53636890
28. Cable Clamp R 8 63733190
29. Screw 5X30 -A2-70 (In6Rd) 73032680
30. Screw 5X30 -10.9-R2R (K-In6Rd) 73030860
31. Screw 5X65-10.9-A2K (Kombi-In6Rd) 63032940
32. Screw 4X 12-St-10.9-R2R (In6Rd) 73030950
33. Screw M4X8 -St-P2R (In6Rd) 73030300
34. Serrated Lock Washer A4,3-Fst-A3E Din67 73122300
35. Screw 3,5X12 -A2-70-Bk (In6Rd) 73031020
36. Cable Harness Br 30/4 C 48225400
37. Piece Of Tube Dn6 350Mm 54410740
38. Spring 0,7X5,2X300 53329730
39. Bearing Shell Kpl. 42500790
40. Hose Clip With Insert 13,3 63887010
41. Strainer Insert Funnel 50332740

saber blade 12

1. Cover Waste Water Tank 50331810
2. Seal Cover Tank Sw 53637110
3. Waste Water Tank Blue 50334910
4. Screw 5X16 -10.9-P2R (K-In6Rd) 73031070
5. Carrier Handle Tank 50331830
6. Fresh Water Tank Blue Replacement 40334920
7. Notch Fresh Water Tank 50331860
8. Fuel Tank Filler Cap Replacement 40331870
9. Seal Float 53637020
10. Float Replacement 40331820
11. Valve Fresh Water Tank 41902580
12. Quick-Fastener 63431490

saber blade 12

2. Cover Enclosure Replacement 40331760
4. Cable Bushing 66480640
5. Turbine Set Usa 44902430
6. Flanged Pulley Pinion 50331940
7. Motor Pinion Z13 M3 50332630
8. Hexagon Nut M 5-A2-70 Iso 4032 73110650
9. Set Of Gaskets 43636900
10. Enclosure Motor 50331760
11. Screw 5X16 -A2-70 (In6Rd) 73031040

saber blade 12

1. Covering Cap Brush-Head Blue 50334860
2. Snap-Fit Wheel 50332080
3. Rubber Pump 53636940
4. Wheel Black D121 55153420
5. Suction Channel Top Part 50332580
6. Pump 64735350
7. Suction Channel Brush-Head 50332070
8. Foot Pedal Complete Only For Replacement 44810000
9. Covering Cap Plate Switch 50332380
10. Screw 4X16 -A2-70 (In6Rd) 73030260
11. Housing Brush-Head 50332000
12. Roller Brush Complete Br 30/4 C 47624280
12. Roller Brush Complete White 47624520
12. Roll Microfibre Complete 47624530
14. Coupler Clamp Block 50332220
15. Screw 4X22 -St-10.9-R2R (In6Rd) 73030960
16. Toothed Belt Set 43484500
17. Screw 5X20 -A2-70 (In6Rd) 73032120
18. Cover Retainer Transmission 50332230
19. Seal Lagerdeckel 53637130
20. Assembly Group Brushes Drive 37630980
21. Locking Ring 10X1-Rf-St Din 471 73430010
22. Roller Set 48800580
23. Spring 53329520
24. Web Suction Bar 50332240
25. Suction Bar Complete 300 47773200
25. Suction Bar Complete Oil Resistant 300 47773240
26. Bumper Replacement 40332020
27. Pedal Suction Bar Grey 50334930
28. Strip Water Distributor 51902550
29. Retaining Bracket Suction Bar 50348030
30. Hose Nozzle 53636980
31. Retaining Bracket Height Adjustment 50348260
32. Wheel 55150690
33. Strain Relief 66475130
34. Washer Wheel 51005910
35. Screw M 5X 12-A2-70 (In6Rd) 73061810
36. Quick-Fastener 63432240
37. Screw 5X30 -A2-70 (In6Rd) 73032680
38. Countersunk Screw 4X20 -A2-70 (In6Rd) 73032690
39. Screw 5X16 -A2-70 (In6Rd) 73031040
40. Coupler Complete 44700430
41. Bracket Brush 50094150
42. Pressure Roller Complete 44700400
43. Cap Coupler 50332690
44. Seal String Cellular Rubber 3 62730370
45. Thread Deflector 50332300
46. Pin Snap-Fit Wheel 50332790
47. Snap-Fit Wheel 50332080
48. Plain Bearing With Collar 50332640
49. Bush 51128630
50. Wheel D121 55153380

saber blade 12

1. Add-On Kit Carpet Cleaning Br 30/4 C 27830050
2. Roller Brush Blue Complete 300 47624990
3. Suction Bar Carpet Cleaning 50332750

-xx. = Not shown on schematic.
