You are here: Home > RAINBOW > Rexair Rainbow D4
Rainbow Vacuum
Model: D4 Add to My Models

D4

XX. Cap & Cap Cover Assy, 4-hole top & bottom R3240
XX. Cap & Cap Cover Assy, w/o baffle FNLA
01. Handle Applique Top R2721
02. Cap Cover Assy, includes handle pad R3160
03. Handle Pad R2584
04. Cap Assy, includes cap applique R4369
05. Screw, plastic H515B
06. Switch, snap-in FNLA
06. Switch, prior to SN 6171010 R2728
07. Handle Applique, side R2722
08. Cap Applique, fits all models R5403
08. Cap Applique, for caps made before 6/93 R2592
09. Outer Baffle Assembly R2764

D4

01. Motor Shroud R2582
02. Screw, plastic H556B
03. Clamp Ring Segment R2172
04. Clamp Ring Segment R2585
05. Motor Support Ring R2701
06. Strain Relief Clip R2607B
07. O Ring, for closure cover R4148B
08. Closure Cover, w/ applique & "O" ring R3845
08. Closure Cover Assy, prior to Sn 6878827 R2708B
08. Latch Assy, for for RX-R2708 R2706B
09. Applique, closure cover R2772
10. Cord, s/n 0000001-7000000 R4052
11. Strain Relief Support R2605B
12. Screw, main housing to cap H515B
13. Baffle Plate Assy R3222
14. Motor Gasket R2702
15. Cable Tie R2380B
16. Power Nozzle Receptacle R3184
17. Main Housing Sub-Assembly FNLA
18. Applique, main housing R4201
18. Applique, main housing, glossy FNLA
19. Latch Only, w/o applique R6178
19. Latch Assy, w/ applique, up to Sn 8000000 78-7514-62
20. Applique, latch, up to Sn 8000000 R4203
21. Latch Spring R2654B
22. Latch Pin R1566B
23. Screw, plastic H491B
24. Water Pan Assy R6854

D4

XX. Motor Assembly R3242
01. Screw, plastic H545B
02. Bearing Bridge Assy R2677
03. Carbon Brush R5125
03. Carbon Brush, up to Sn 7520714 R2421
04. Brush Holder Clip R2703B
05. Field Assy R3159
06. Motor Base & Bearing Assy R2773
07. Motor Base Assy R2636
08. Fan Spacer, top R2680B
09. Fan Spacer, middle R2681B
10. Fan Spacer, lower R2679B
11 . Stage Housing Clip R2682B
12. Lower Housing & Inner Baffle Plate Assy R2774
13. Ball Bearing R1981
14. Bearing Retainer Shield R2630B
15. Spider R4101
16. Lower Housing Assy R4612
17. Screw H542B
18. Nut, armature shaft FNLA
19. Separator Nut, flat H555B
20. Fan, motor R3277
21. O Ring R2936B
22. Wave Washer R2525B
23. Insulator Washer R2946B
24. Armature Assy R5319
25. Brush Holder R5124
25. Brush Holder, up to Sn 7520714 R2700
26. Bearing Boot R1987B
27. Upper Stage Assy R2613
28. Fan Assy R2609
29. Lower Stage Assy R2617
30. Slinger Ring R1979B
31. Outer Baffle Plate R2698
32. Motor Gasket Flange R747
33. Separator R4100
34. Ball Bearing R5238

D4

01. Screw H515B
02. Bottom Plate Assy R2004
03. Insulator R1997
04. Screw H552B
05. Air Barrier R1813
06. Motor Assy R1871
06. Carbon Brush, p/n motor R4662B
06. Rear Bearing, p/n motor R4663B
06. Sleeve Assy, p/n motor R3550
07. Seal, brush assy R1692B
08. Keeper, brush assy R1691
09. Thrust Washer R1698B
10. End Cap R2443B
11. Power Nozzle Pulley Assy R3472
12. Belt, sold each R1699B
13. Pivot Arm Assy R2801
13. Pivot Arm & Housing Assy R3300
14. Felt Pad R2069
15. Wheel, p/n R1703
16. Main Housing Assy FNLA
17. Bumper R2795
18. Gasket, bottom plate R2003
19. Pilot Light Assy R1818B
20. Closed End Splice R1775B
21. Lead Assy R1754
22. Insulator, circuit breaker FNLA
23. Circuit Breaker, 2 amp R11077
24. Adaptor Plate, curcuit breaker FNLA
25. Bearing Assy R1744B
26. Brush Roll Only R1690
27. Beater Bar R1695
28. Pivot Housing R2803
29. Clevis Pin R1996B
30. Wheel Pins, p/n R1704B
31. E Ring H527B
32. Brush Roll Assy, complete R1866

D4

01. Hose Cord Strap R1045B
02. Curved Wand Assy FNLA
03. Straight Wand Assy R5066
04. Lens, right-hand FNLA
05. Applique, right-hand FNLA
06. Applique, satin FNLA
06. Applique, glossy R2793
07. Slide Valve Guide Assy R2775
08. Slide Valve R1990
09. Power Nozzle Cord R2496
10. Lens, left-hand R2685
11. Applique, left-hand FNLA
12. Strain Relief Bushing R4053B
13. Pilot Light Lens FNLA
14. Hose Assembly R6621
14. Hose Coupling Assy R2784
14. Hose & Molded Tip FNLA
14. Molded Tip R579
15. Wand Cord Strap R1045B
15. Cord Guide Replacement Kit R3520

D4

01. Front Plate R2269
02. Aquamate Head Decal R3581
03. Extraction Head Assy, complete FNLA
04. Straight Wand Assy R2846
05. Bottle Latch R2322
06. Latch Spring FNLA
07. Right Housing Assy FNLA
08. Scrrew H537B
09. Slide Adjustment FNLA
10. Pinch Arm R2318
11. Bent Wand Assy R2849
12. Trigger FNLA
13. Trigger Spring R6977B
14. Valve Cpntrol Rod Assy FNLA
15. Fluid Control Assy R2400
16. Hose Conn FNLA
17. Hose Connection FNLA
18. Detergent Inlet Tube R2602
19. Overflow & Bottle Fill Tube FNLA
20. Left Housing Assy FNLA
21. Foam Gasket R2317
22. Flow Control R7351
23. Solution Bottle Assy FNLA
24. 40 tube FNLA
25. Nozzle Clean-Out Tool FNLA
26. Sprayer Nozzle/Plate Kit R2260
27. Screw H491B
28. Brush Assy R2262
29. Long Adaptor Washer R2080B
30. Screen Washer R7356B
31. Stem Nut R6138B
32. Tubing Clamp R2040B
33. 50 ft Hose Assy FNLA
33. 50 ft Hose (included) FNLA
34. Anti-Drip Washer FNLA
35. Washer, short adaptor R2079B
36. Adaptor, short R2045
37. Control Network Assy, complete FNLA
37. Swivel Stem, white piece R2042B
XX. Straight Wand FNLA
XX. Curved Wand 78-1902-07
XX. Suction Control Sleeve R2792
XX. Bottom Wand FNLA
XX. Floor Tool Assembly 78-1500-61
XX. Body w/ Logo Only, floor tool FNLA
XX. Bristles, floor tool R2540
XX. Guard, floor tool R11038
XX. Crevice Tool 78-1802-62
XX. Dusting Brush Assy R12439
XX. Bristles, dusting brush R192
XX. Body w/ Logo Only, dusting brush FNLA
XX. Upholstery Tool Assy R2535
XX. Brush, upholstery tool R2537
XX. Body w/ Logo Only, upholstery tool R3079
XX. Rainbow Logo FNLA
XX. Coil Cleaner R4142
XX. Inflator Tool Assy R3358
XX. Attachment Caddy R2709
XX. Pin, caddy swivel arm R3816
XX. Spring, caddy swivel arm H564B
XX. E-Ring, caddy swivel arm FNLA
XX. Hose, w/ molded tip, all except D4CSE FNLA
XX. Hose Coupling Assy R2784
XX. Hose Tip Only R579
XX. Separator Brush R841
XX. Dolly, w/o casters R2811
XX. Caster, sold each R2812
XX. Applique, dolly, glossy FNLA
XX. Applique, dolly, satin FNLA
Sort By:
Page of 16
Rexair Belt, Power Nozzle Rexair Water Pan, 2 Qt, D4
Rexair Belt, Power Nozzle #R1699B
List Price $3.74
Sale Price $3.12
You save $0.62!
Rexair Water Pan, 2 Qt, D4 #R6854
List Price $43.00
Sale Price $35.83
You save $7.17!
Usually ships Same Day / Next Day Usually ships Same Day / Next Day
Rexair Latch, Rainbow Rexair/Rainbow Floor Tool
Rexair Latch, Rainbow #R6178
List Price $8.50
Sale Price $7.08
You save $1.42!
Rexair/Rainbow Floor Tool #78-1500-61
List Price $13.46
Sale Price $11.22
You save $2.24!
Usually ships Same Day / Next Day Usually ships Same Day / Next Day
Rexair/Rainbow Latch Assembly Plastic Black Rexair Spring, Latch R2654
Rexair/Rainbow Latch Assembly Plastic Black #78-7514-62
List Price $6.28
Sale Price $5.23
You save $1.05!
Rexair Spring, Latch R2654 #R2654B
List Price $4.10
Sale Price $3.42
You save $0.68!
Usually ships within 7 days Usually ships Same Day / Next Day
Rexair Separator Rexair Gasket, Motor
Rexair Separator #R4100
List Price $25.90
Sale Price $21.58
You save $4.32!
Rexair Gasket, Motor #R2702
List Price $14.58
Sale Price $12.15
You save $2.43!
Usually ships Same Day / Next Day Usually ships Same Day / Next Day
Rexair Latch Pin, Rexair Motor Brush
Rexair Latch Pin, #R1566B
List Price $4.39
Sale Price $3.66
You save $0.73!
Rexair Motor Brush #R2421
List Price $31.02
Sale Price $25.85
You save $5.17!
Usually ships Same Day / Next Day Usually ships within 3 days
